Corrugated Sheet Cold Roll Forming Machine

FOB Reference Price / Min.Order Quantity : Get Latest Prices
Processing Time: 1 Days - 60 Days
Packaging Details: STANDARD EXPORTING PACKAGE

Port: Shanghai / Shenzhen / Qingdao / Ningbo / Other

Payment Terms: L/C , T/T , other

Share to:

Basic Information

  • Model Number
    LSAZ

Brief description

FOB Price:US $ 12,000 - 16,000 / Set

Min.Order Quantity:1 Set/Sets

Supply Ability:20 Set/Sets per Month

Port:Dalian Port

Payment Terms:L/C,D/A,D/P,T/T,Western Union,MoneyGram

Detailed description



Quick Details

  • Place of Origin: Liaoning, China (Mainland)
  • Brand Name: Longshun
  • Model Number: LSAZ
  • After-sales Service Provided: Engineers available to service machinery overseas
  • machine type:: corrugated sheet machine
  • Coil width:: 1m
  • Thickness: 0.3-1.0mm
  • Weight:: 7 t
  • Device Length:: 9m
  • Width:: 1.4m
  • Height:: 1.5m
  • Motor power:: 5kw
  • voltage:: 380v
  • Supply:: three-phase power

Packaging & Delivery

Packaging Details:Standard waterproof packageDelivery Detail:Within 20 days since the date of downpayment received

Specifications



The Corrugated Sheet Making Machine
A top quality
B.high technology
C.reasonable price
D.easy operatio








   Corrugated Sheet Cold Roll Forming Machine







Brief introduction



Yingkou Longshun Machinery Manufacturing Co., Ltd. is an enterprise professionally engaged in research,design,construction and installation.Our company takes producing color steel forming equipment series as the central task.The main production contain arch sheet machine,composite sandwich plate machine,purlin machine,flat sheet machine,and guardrail roll forming machine.



Machine Components:

De-coiler

1 set

Forming machine

1 set

Production support table

1 set





Parameters of the machine :



No.

Spc.

1

suitable material

Color Steel plate, galvanized sheet

2

Feeding width

1000mm

3

Rows of rollers

16 rows

4

Main power

5.5kw

5

Hydraulic power

4kw

6

Thickness of raw material

0.3-1.0mm

7

Transportation system

Chain transportation

8

Thickness of chain

1.2 inches

9

Effective Width

840mm

10

Out diameter of shaft

80mm (solid shaft)

11

Material of shaft

45# steel forged by the Carbon at high temperature

12

Roller material

40Cr steel polished and coated with chrome HRC55-60°

13

Shear mould

Cr12

14

Voltage

380V 50Hz/60Hz 3phases

15

Control system



PLC Frequency Control System with touch screen

16

Total Weight

7 tons




Our company is an enterprise professionally engaged in the research, design, construction and installation. Our company is located in Yingkou City SME park, covering an area of over 18,000 square meters. Near Dalian Highway, our transportation is very convenient. The company has a number of technical staff members, including mechanical engineers, civil engineers, and construction technicians and a strong construction team.

Our company takes producing color steel forming equipment series as the central task. Our main production equipment contains arch sheet machine, composite sandwich plate machine, C shape purlin machine, Z shape purlin machine, flat sheet corrugated, glazed tile roll forming machine, granary machine, bending machine, slitting machine and guard rail forming machine. We sell them around the world receiving the high praise from domestic and international customers.

Longshun people persist in pioneering and enterprising. We regard customers' needs as our driving force and attribute our success to customer approvals. What makes Longshun dominate the market is that we always provide customers with the best products.
