The laser power meter manufactured by CNI is an optoelectronic device. The main principle is to attenuate the energy by colored optical glass and to receive the residual energy by photoelectric cell uniformly. The power meter has been tested for many parameters, such as, linearity, repeatability, uniformity, longterm stability and so on. The measurement range of this power meter is from 0.01 milliwatt to 10 watts.

Product Details

Parameter

Place of Origin : Jilin, China (Mainland)
Model Number : TS15
Brand Name : CNI
Display Type : Analog and Digital
Phase : Three Phase
Measuring Energy Range : 10mW-15W
Accuracy Class : 0.1-10mw
Wavelength range : 0.19-11um
power range : 10mW-15W
resolution : 0.1-10mw

Description

Packaging & Delivery

Delivery Detail: 2 weeks





The laser power meter manufactured by CNI is  an optoelectronic device. The main principle is to attenuate the  energy by colored optical glass and to receive the residual energy by photoelectric cell uniformly.  The power meter has been tested for many parameters, such as, linearity, repeatability, uniformity, longterm stability and so on. The measurement range of this power meter is from 0.01 milliwatt to 10 watts. Furthermore, the measured wavelengths from 400 nm to 1064 nm, such as 457 nm, 473 nm, 532 nm, 593.5 nm, 635 nm, 660 nm, 671 nm, 808 nm, 980 nm etc.



Features:

 Connect with PC by USB

 With background light digital and analog display on the screen

 Measuring range 1nW-30kW

 Hand-held power meter, easy to carry

















Wavelength Range

0.19~11μm

Cable Length

1.5m

Power Range

10mW~15W

Cooling Method

Air

Resolution

0.1~10mW

Storage Temperature

-10~60°C

Active Area Diameter

20mm

Range of Use

5~45°C

Max. Average Power Density

25KW/cm2

Reference Conditions

21±4°C

RH:20~80%

NEP(Noise Equivalent Power)

3mW

Response Time
(0
~90%)

<1sec.(a)

Notes

a. Accelerated by LaserPoint electronics

b. Detector centrally irradiated @50% of useful surface

Linearity

±1%(b)

Cable Type

USB2.0 and RS-232 connector

Microcircuit integrated interface

Meters

LP100
