Roof Sanwich Panel

Roof Sanwich Panel
  • Roof Sanwich Panel
Share to:

Min.Order Quantity: 1000 Square Meter/Square Meters Port: main port ofChina Payment Terms: L/C,T/T

Product Details

Description

Quick Details

  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: HUIDE
  • Model Number: Roof Sanwich Panel
  • Panel Material: Metal
  • Type: EPS Sandwich Panels
  • variety: roof

Specifications



Building villas, industrial buildings, warehouses, cold storage, cabin, original works in floor construction.



The company color is a color steel sandwich composite panels for the surface layer to glass cotton, wool, polystyrene and other light, fire, flame-retardant material of the core layer of new building materials, with light, heat good, sound absorption and good sealing performance, easy construction period is short, comprehensive low cost, bending, corrosion resistance, beautiful appearance and other obvious advantages.

Main use:

Building villas, industrial buildings, warehouses, cold storage, cabin, original works in floor construction, can be flexibly used in any construction.

Quality Characteristics:

       1, light weight, 10-14 kg / square meter, very walls of 1 / 30.

       2, thermal insulation, thermal conductivity: 0.035W/mk.

       3, high intensity, can be used for building envelope, bearing structure, bending compression, general housing without pillars.

    Technical Data:

1, thickness: (1) color plate thickness (mm) :0.35-0 .80

                    (2) sandwich thickness (mm) :40-300

2, length (mm): Open

3, the effective width (mm): wall 1200,1150,950

                                          Roof 950

4, the average sound volume:





Thickness(mm)

50

75

100

150

R(dB)

20.00

21.50

23.00

24.50







5, heat transfer coefficient:





Thickness(mm)

50

75

100

150

W/m2k

0.663

0.442

0.330

0.220

Keal/m2.h.°C

0.570

0.380

0.280

0.190



6, to allow the maximum span:



           Thickness(mm)

Load(kg/m2)

continuous

simple supported

50

75

100

50

75

100

50

3.90

5.00

9.50

3.45

4.30

7.80

100

3.40

4.15

5.80

2.95

3.70

4.90

150

2.75

3.35

4.75

2.40

2.90

4.10



7, temperature 75 º C continuous and durable

Note: The above table data to 0.5mm color plates, polystyrene density of 16kg / m² based on measured



Company Profile

Shandong Boxing Huide Iron&Steel Co., Ltd is a professional large-scale manufacturer of steel sheet and steel structure, integrating development and production together. Our parent company is Shandong Hahi New Material Co., Ltd. Our main products include PPGI (Pre painted galvanized steel coil, Galvanized steel coil, Corrugated iron sheet, Sandwich panel and other steel structures to apply for building, transporting, house applying. We currently have 4 lines for producing the four main products.
Our company was established in 1993, and we have many years of history in the steel field. Located in Qingdao, we enjoy convenient water, land and air transport. We have got the ISO certification in 2000. We can produce PPGI without lead, and ROHS certification are available, therefore having a good market in china. Our products have been exported to many countries, some of them were used to build Pepsi plant and airport.
Since we have been in steel business field for a long time, and have a good relationship with many chinese major steel enterprises such as Bao steel, we are the local distributor of them. So we can provide various grades of products for our customers.
We believe that our development is on the base of our customers' development, so we always provide first class product and service to them. If you choose our product, you are surely will be satisfied with their price and quality.
