FOB Price:US $ 1,000 - 10,000 / Ton
Min.Order Quantity:5 Ton/Tons
Supply Ability:10000 Ton/Tons per Month
Port:Dalian
Payment Terms:L/C,D/A,T/T
Specifications
Smetal indefinite chilled alloy cast roll
1 ISO cert.
2 Anti stripping
3 Good thermal cracking resistance
4 wear resistance.
Smetal indefinite chilled alloy cast roll
-Feature
1 ISO cert.
2 Anti stripping
3 Good thermal cracking resistance
4 wear resistance.
-Chemical ingredients
NO. |
C% |
Si% |
Mn% |
Ni% |
Cr% |
Mo% |
IC |
3.1-3.4 |
0.6-0.9 |
0.5-1.0 |
- |
0.7-1.1 |
0.2-0.6 |
IC-1 |
3.1-3.4 |
0.6-0.9 |
0.5-1.0 |
0.6-0.8 |
0.7-1.1 |
0.2-0.6 |
IC-2 |
3.1-3.4 |
0.6-1.0 |
0.5-1.0 |
2.2-2.8 |
0.7-1.1 |
0.2-0.6 |
IC-3 |
3.1-3.4 |
0.6-1.0 |
0.5-1.0 |
2.2-2.8 |
0.8-1.3 |
0.2-1.0 |
IC-4 |
3.1-3.4 |
0.6-1.0 |
0.5-1.0 |
3.1-4.3 |
1.0-1.3 |
0.2-1.0 |
IC-5 |
3.1-3.4 |
0.8-1.2 |
0.5-1.0 |
3.8-4.5 |
1.4-2.0 |
0.2-1.2 |
-Physical property
NO. |
Hardness of roll body |
Hardness of roll neck |
tensite strength |
IC |
50-70 |
35-55 |
>160 |
IC-1 |
55-72 |
35-55 |
>160 |
IC-2 |
55-72 |
35-55 |
>160 |
IC-3 |
65-78 |
35-55 |
>350 |
IC-4 |
70-83 |
35-55 |
>350 |
IC-5 |
77-82 |
35-55 |
>350 |
-Metallurgical structure
No |
metallurgical structure |
IC |
pearlite+cementite+a small amount of graphite |
IC-1 |
nodular pearlite+cementite+a small amount of graphite |
IC-2 |
nodular pearlite+cementite+a small amount of graphite |
IC-3 |
sorbite+cemenite+a small amount of graphite |
IC-4 |
tempered martensite+carbonide tempered martensite +carbide |
IC-5 |
tempered sorbite+bainite+carbonide+graphite |
-Range of application
IC-IC3:profile material,rod-wire material,narrow strip stell rolling mill intermediate rolling,finishing stand
IC4: profile material,rod-wire material,narrow strip stell rolling mill finishing stand,mid-thickness plate,strip steel finishing rolling
IC5:Mid-thickness plate,strip stell finishing rolling
-Manufacturing specification
Roll diameter<1400mm,
Roll length<4500mm
