Product Description
Head pulley and driving pulley and drum pulley for full handling machine.
Conveyor pulley stays at two ends of belt machine to drive the belt to hand the material and to change the belt running direction. Conveyor pulley is the very important part on belt conveyor which guides the belt running. There are kinds of pulleys we supply, like driving pulley, bend pulley, coating pulley. Regarding the rubber coating pulleys, there are vulcanized pulleys and cold adhesive pulleys. The type of rubber surface could be flat, herringbone and rhombic.
Specifications
Our pulleys are characterized by reasonable structure and reliable performance, various types, steady running, smooth rotating,
Product Description
Head pulley and driving pulley and drum pulley for full handling machine.
Conveyor pulley stays at two ends of belt machine to drive the belt to hand the material and to change the belt running direction. Conveyor pulley is the very important part on belt conveyor which guides the belt running. There are kinds of pulleys we supply, like driving pulley, bend pulley, coating pulley. Regarding the rubber coating pulleys, there are vulcanized pulleys and cold adhesive pulleys. The type of rubber surface could be flat, herringbone and rhombic.
Specification
Type
|
Belt Width
|
Standard Diameter(mm)
|
Length
|
Drive pulley, bend pulley
|
500
|
500
|
depends on the belt width
|
650
|
500-630
|
800
|
630-1000
|
1000
|
800-1150
|
1200
|
800-1150
|
1400
|
1000-1350
|
1600
|
1150-1600
|
1800
|
1150-1800
|
2000
|
1350-2000
|
2200
|
1600-2200
|
2400
|
1800-2400
|
Features
- High self-cleaning effect
- High resistance to wear
- High reliability even in wet
- the friction force increased at end
- Changeable covered surface to extend the lifespan
All the pulleys we supply adopt integrated bearing house which is lubricated and filled with grease and has two kinds: iron casting and steel casting, the shaft is made of 45# steel, the shell adopt weld assembly.
Application
Our products are widely used in coal mines, metallurgy, machinery, ports, construction, electricity, chemistry, food packing and other industries.
Advantages
Owning to the professional assembly line for pulleys, our company can supply various pulleys: head pulley, tail pulley, drive pulley, bend pulley, motorized pulley, magnetic pulley, rubber pulley and casting pulley.
We adopt advanced technology to produce thick pulley shell which can absorb more stress and offer advantages as maximum contact with belt, reducing shaft deformation and stress on the bearing, to ensure functioning.
Regarding the rubber coating pulleys, there are vulcanized pulleys and cold adhesive pulleys. The type of rubber surface could be flat, herringbone and rhombic.
Our pulleys can work in the dusty, wet, muddy or other harsh environments.
