GTB tension meter is hand-held digital Tension measuring instrument.

Product Details


Power : Electronic
Usage : Textile Testing Instrument


Yarn wire digital tension meter


General information:

GTB tension meter is hand-held digital Tension measuring instrument, it can accurately measure the tension and systematic data processing.

Special feature:

  1. GTB tension meter can accurately measure up to 10 different materials to achieve accurate measurement of each material.
  2. accuracy ±0.5%FS(full scale)
  3. Tension meter allows the customer to adjust the measurement result by plus or minus 7×1.5%FS(full scale)
  4. Tension meter can record maximum, minimum, peak of maximum , peak of minimum and average value over a period of testing time.
  5. Adjusting electronic damping can adjust the display update rate, provides three selection: 0.5s,1s,2s.
  6. GTB tension meter has USB interface which can be connected to computer to display measurement process by waveform, record the measurement data over a period of testing .the storage rate is 200HZ.
  7. die-casting aluminum body: durable, anti vibration, anti electromagnetic interference
  8. tension range from 0-200gf to5.00-50.00kgf.  20kg , 30kgf and 50kgf level arm for easily using.


APPLICATION:   The applications for GTB tension meters are many and varied. They will be found both in the laboratory and in producing textiles, wire, cable, tire cord, carbon fibers and magnetic tapes.

Applications in textile industry: e. g. 50 up to max. 50000 tex

Applications in wire industry: e. g. 0.08 up to 2.2 Ø mm copper wire


FOB pirce:     950 USD

Supply ability:1000pics/year

Min order quantiy:1 pics

Payment term: T/T
