2015-2016 low cost HGM Grinding Mill for minerals

2015-2016 low cost HGM Grinding Mill for minerals
  • 2015-2016 low cost HGM Grinding Mill for minerals
Share to:

2015-2016 low cost HGM Grinding Mill for minerals

Product Details

Description

Hot Selling 2015-2016 low cost HGM Grinding Mill for minerals

with Good Performance



Product Description of 2015-2016 2015-2016 low cost HGM Grinding Mill for minerals
— — Five models: HGM80, HGM90, HGM100, HGM125, and HGM1680L
— — Finished production fineness: 300meshes~3000meshes, 5-74micron
— — The capacity (ton/hour) ranges from 0.4T/H to 30T/H






Application of Hot Selling 2015-2016 2015-2016 low cost HGM Grinding Mill for minerals with Good Performance:
HGM Series 2015-2016 2015-2016 low cost HGM Grinding Mill for minerals is the equipment specializing in producing fine and superfine powder of non-inflammable, non-explosive and brittle materials with Moh's hardness under six, such as calcite, chalk, limestone, dolomite, kaolin, bentonite, talc, mica, magnesite, illite, pyrophyllite and vermiculite, sepiolite, attapulgite, rectorite, diatomite, barite, gypsum, alunite, graphite, fluorite, rockphosphate, Kalium ore, pumice, etc., totally more than 100 kinds of materials.


Work Principle of Hot Selling 2015-2016 2015-2016 low cost HGM Grinding Mill for minerals with Good Performance:
HGM series 2015-2016 2015-2016 low cost HGM Grinding Mill for minerals mainly consist of main unit, classifier, powder collector, dust cleaner, blower, muffler, sound-proof room, crusher, bucket elevator, storage hopper, and vibrating feeder.
Features of Hot Selling 2015-2016 2015-2016 low cost HGM Grinding Mill for minerals with Good Performance:
High Efficiency
Under the same finished final size and the same motor power, the capacity of 2015-2016 2015-2016 low cost HGM Grinding Mill for minerals is twice as much as jet mill, mixing grinder and ball mill, and energy consumption decreased 30%.
Long lifecycle of spare parts
The ring and roller are forged by special material with high utilization, the lifetime can reach 2-5 years for grinding calcite carbonate.
High safety and reliability
As no rolling bearings or screws in grinding cavity, there are no problems caused by bolts shedding or rapid wear of bearings and seal components.
High fineness, flexible adjustment
The final fineness of the grinding materials can be adjusted between 325 meshes and 2500 mesh (47-5 micron), and the product fineness can reach D97≤ 5μ M.
Environment-friendly
The application of pulse bag filter and muffler greatly alleviates dust pollution and noise.
Advanced intelligent speed control device
Convenient adjusting, more uniform particle size.



About Us

Shanghai Clirik Machinery CO., LTD. is a professional supplier with more than 15 years’ experience, who supply all kinds of grinding mills, including ball mill, YGM Raymond mill, HGM ultrafine mill, mirco grinding mill, vertical grinding mill, and crushers, including Jaw crusher and hammer crusher, and other auxiliary equipments.



Q&A
1. What advantages does your 2015-2016 2015-2016 low cost HGM Grinding Mill for minerals have?
— The main advantage of our sepiolite powder making machine over other kinds of mills is that you can grind a friable or crystalline material to 5 - 74 microns average particle size and classify in a very narrow particle size range at the same time. There are no moving parts to wear out or generate heat in our mill and no screens to plug or be punctured.
2. Can you guarantee the quality of your 2015-2016 2015-2016 low cost HGM Grinding Mill for minerals?
---We have passed CE&ISO9001: 2008, and our crushers have been exported to Eastern Europe, Middle East, Africa, South Asia, Southeast Asia, Oceania, America, etc.
3. How many years have you been manufacturing the machine?
---8 years. Since the foudation of our company, we have been manufacturing the machine, which updated many times, now the machine runs stable and of high quality
4. How do you adjust particle size in your 2015-2016 2015-2016 low cost HGM Grinding Mill for minerals?
— Particle size is adjusted primarily by a change in feed rate. When the rate is reduced, finer particles result because there is more energy available per particle to accelerate the particles and the entire fluid mass. Collisions become more violent and pressure gradients become larger.



Main Specification of 2015-2016 2015-2016 low cost HGM Grinding Mill for minerals:

Model HGM80 HGM90 HGM100 HGM125 HGM1680L
Ring Diameter(mm) 800 900 1000 1250 1680
Ring Number (PCS) 3 3-4 4 4 4
Roller Number(PCS) 18-21 24-29 28-36 30-44 30-40
Main Shaft Speed (r. p. min) 230-240 200-220 180-200 135-155 120-130
Input Size (mm) ≤10 ≤10 ≤15 ≤15 ≤20
Finished Size (um/mesh) 74-5
(200-2500)
74-5
(200-2500)
74-5
(200-2500)
100-6
(150-2000)
100-9
(150-1500)
Capacity (t/h) 0.4-4.5 0.6-6.5 1-9 2-16 3.8-30
Outlet Size L*W*H (m) 13.9*4*6.2 14.7*4.8*7.2 18*4.6*8.6 14*9*10.25 26.3*7.5*11.9



Company Profile

Shanghai Clirik Machinery CO., LTD. is a professional manufacturer and supplier with more than 15 years’ experience, who supply all kinds of grinding mills, including ball mill, YGM Raymond mill, HGM ultrafine mill, mirco grinding mill, vertical grinding mill, and some crushers, including Jaw crusher and hammer crusher, and other auxiliary equipments.
