Type: Doppler Ultrasound Equipment, color doppler ultrasonic
Brand Name: Xian Feng
Model Number: XF7000
Place of Origin: Sichuan, China (Mainland)
Monitor: 15 inch LCD screen with rocker
Display mode: B, B/B, 4B, B/M, M, B+C, B+D, B+C+D, PDI, CF, PW
OEM service: offer
CE: offer
warranty service: 2 years
hightech: Full digital
palce of origin: Mianyang sichuan China
screen size: 15 inch/17inch
power: 120-240V 50HZ
Specifications
1.Advanced Imaging Technology
2.Technologies of 4D volume rendering
3.Real-time 4D Technology
Application
For OB/GYN applications
we supports high performance,lightweight transducers for volume acquisitions.The 4D edocavity transducer supports high resolution single-sweep acquisitions that can be saved and reviewed on a seperate computer.
Cardiac and CW
Supports phased array transducers for adult and pediatric cardiac imaging applications.A separete continuous wave beamformer improves spectral signal-to-noise ratio.
Breast
With high frequency linear transducer and high performance modes optimizing image quality to diagnosis of breast pathology and freehand elastography to measure tissue stiffness in the breast.Our unique 2D color map uses special exclusion algorithms to clearly highlight stiff tissue in real time.
Vascular
Multiple linear transducer for all vascular exams supports color and PW doppler,triplex,beam steering,angle correct,simultaneous 2D/color.Easy to use measurements and detailed report package.
Musculoskeletal
Linear transducers support 2D color imaging,Power doppler,etended field of view and Panoramic imaging.
Abdomen
Supports pulse inversion harmonics spatial compounding and advanced adaptive speckle reduction.Sensitive color flow images demonstrate clinical vascularity.
3D /4D color doppler ultrasound system
Sound velocity imaging technology optimization
color doppler energay (CDE)
continuous wave doppler imaging (CW)
pulse wave doppler imagaing(PW)
color doppler resolution enhancement
panoramic imaging. space compund imaging
adaptive speckle noise suppression techniques
ergonomic design. all-round display angle adjustment
three activated ports . 15/17 ''HR madical monitor
One Touch optimize under different modes.
Technical Specification
No.
|
Item
|
Index
|
<1>
|
Depth
|
≥300mm
|
<2>
|
Lateral Resolution
|
≤1mm (Depth≤80mm)
≤2mm (80< Depth≤130mm)
|
<3>
|
Axial Resolution
|
≤1mm (Depth≤80mm)
≤2mm (80< Depth≤130mm)
|
<4>
|
Blind Area
|
≤5 mm
|
<5>
|
Geometry Position Precision
|
horizontal≤10%
vertical≤10%
|
<6>
|
Channels
|
64
|
<7>
|
Displayer
|
15” LCD (PAL displayer is optional)
|
<8>
|
External Display
|
PAL, VGA
|
<9>
|
USB Ports
|
2
|
<10>
|
Gray Scale
|
256 levels
|
<11>
|
Voltage
|
AC220V ±10%
|
<12>
|
Current
|
3A
|
<13>
|
UPS-DP
|
DC12.8V 11.5A
|
<14>
|
Input Power
|
≤ 300VA
|
<15>
|
Continuous Working Hours
|
≥8h
|
<16>
|
Scanning Mode
|
B, B/B, 4B, B/M, M, B+C, B+D, B+C+D, PDI, CF, PW
|
Our advantage
There are 3 good reason to choose us!
1.we are real manufacturer ,specializing in R&D ,design ,production and sales of medical B ultrasound systems.
2.Our technical deparment can change our B ultrasound to meet you and your costomer ‘s special request .such like put your company ‘s logo in software, OEM etc.
3.Many domestic trade companies buy our B ultrasound for export , our B ultrasound have high reputation in overseas markets . if you buy from our factory directly , you will get faster delivery ,much longer quality assurance.more technical support ,and attractive price! You will got more profit than anywhere else , Because we work hard for you which gives you a lot of positive contribution!!
