1T, 3.5M Full Electric batteries forklift 24 v With CE

FOB Reference Price / Min.Order Quantity : Get Latest Prices

Processing Time: 1 Days - 60 Days

Packaging Details: STANDARD EXPORTING PACKAGE

Port: Shanghai / Shenzhen / Qingdao / Ningbo / Other

Payment Terms: L/C , T/T , other

Send Inquiry Add to My Favorites

Share to:

Basic Information

After-sales Service Provided

Overseas service center available
Certification

CE/ISO9001
Overall Dimensions

1780x740x2080mm
Fork Width

1070mm
Fork Length

680mm
Min. Lifting Height

85mm
Max. Lifting Height

3500mm
Rated Loading Capacity

1000KG
Power Souce

DC Motor
Type

Full electric forklift truck
Model Number

VR-PWS-100/35
Brand Name

self brand
Place of Origin

Guangdong, China (Mainland)
Condition

New

Brief description

New design electric stacker completed with heavy duty integrated power pack for lifting and motorized wheel for driving. Two speeds electric control.Just slightly turn forwards or backward the handle you could easily move a heavy cargo.

Detailed description

Packaging & Delivery

Packaging Details:	Plywood package
Delivery Detail:	Shipped in 10 days after payment

Product Description

VR-EMS 1T, 3.5M Full Electric Stacker With CE Certification

New design electric stacker completed with heavy duty integrated power pack for lifting and motorized wheel for driving.
Two speeds electric control.Just slightly turn forwards or backward the handle you could easily move a heavy cargo.
CE is available

Specification

Model	vr-pws-100/16	vr-pws-100/20	vr-pws-100/25	vr-pws-100/30	vr-pws-100/35
Fork Lift Height	1600mm	2000mm	2500mm	3000mm	3500mm
Fork Dimension	1070x150x60mm	1070x150x60mm	1070x150x60mm	1070x150x60mm	1070x150 x60mm
Width Over Fork	550mm	550mm	550mm	550mm	550mm
Ground Clearance	25mm	25mm	25mm	25mm	25mm
Lowered Fork H.	85mm	85mm	85mm	85mm	85mm
H. Overall Extended	2080mm	2330mm	3040mm	3540mm	4040mm
Head Dimension	675x760x755mm	675x760x755mm	675x760x755mm	675x760x755mm	675x760 x755mm
Loading Center	600mm	600mm	600mm	600mm	600mm
Wheel Base	1137mm	1137mm	1137mm	1137mm	1137mm
Turning Radius	1305mm	1305mm	1305mm	1305mm	1305mm
Support Wheel	Φ100x50mm	Φ100x50mm	Φ100x50mm	Φ100x50mm	Φ100x50mm
Front Wheel	Φ80x85mm	Φ80x85mm	Φ80x85mm	Φ80x85mm	Φ80x85mm
Drive Wheel	Φ250x80mm	Φ250x80mm	Φ250x80mm	Φ250x80mm	Φ250x80mm
Overall Size (mm)	1785x760x2080	1785x760x1580	1785x760x1830	1750x760x2080	1750x760 x2330
Lift Load	75mm/s	75mm/s	75mm/s	75mm/s	75mm/s
Speed Unload	150mm/s	150mm/s	150mm/s	150mm/s	150mm/s
Lower Load	100mm/s	100mm/s	100mm/s	100mm/s	100mm/s
Speed Unload	50mm/s	50mm/s	50mm/s	50mm/s	50mm/s
Travel Load	5km/h	5km/h	5km/h	5km/h	5km/h
Speed Unload	6km/h	6km/h	6km/h	6km/h	6km/h
Drive Motor	24V/700W	24V/700W	24V/700W	24V/700W	24V/700W
Lift Motor	24V/2.0KW	24V/2.0KW	24V/2.0KW	24V/2.0KW	24V/2.0KW
Controller	1207A-4102	1207A-4102	1207A-4102	1207A-4102	1207A-4102
Battery	2x12V/70Ah	2x12V/70Ah	2x12V/70Ah	2x12V/70Ah	2x12V/70Ah
Battery Charger	DC 24V/15A	DC 24V/15A	DC 24V/15A	DC 24V/15A	DC 24V/15A
Weight	400Kg	416Kg	456Kg	495Kg	535Kg
Load Gradeability	6%	6%	6%	6%	6%
Unload Gradeability	10%	10%	10%	10%	10%
Width of Aisle	900mm	900mm	900mm	900mm	900mm

Product detail

Company Profile

1. What we specialize in?
Handling equipment, electric forklifts, diesel forklifts, stackers, pallet trucks, drum lifters, and the parts of these equipments.

2. What certification did we get?
CE, ISO9000

3. Why choose us?
High-end quality, reasonable price, good after sale service for the lifelong. Punctual delivery time.

4. Welcome OEM

Verace is specialize in Handling Equipment, Such as Forklifts, Stackers, Pallet trucks, Drum lifters, and so on. Our products passed CE certification. Our factory with 30000 square size, and hign technonogy processing machines, producing the high quality products to input the market which around of the world. For our factory's unity efforts, We get ISO9000 certification and make our factory flourishing . We admire with the high quality, hight efficiency, best service reward the customers.
