Auto Feeding CNC Wood Lathe from China
Advantage of EagleTec Automatic Wood Lathes
• Whole lathe base is casted in one piece from iron, and this structure is obviously superior to the welded one on performance of rigidity and reliablity.
• Auto feeding mechanism with air actuated clamping system improves the wood-turning output greatly. Additionally, this design reduces labor resource, in turn, which reduces labor costs for you. Below are pictures of it.
![auto feeding cnc wood lathe]()
Rotary axis is driven by a 4.0kw (5.36hp) AC servo motor, instead of a 3-phase asynchronous motor. It is the top one thing you should know before buy a cnc lathe for wood.
![cnc wood lathe machine with auto feeding]()
Quick Details of CNC Automatic Wood Lathe Machine
• Truely automatic workpiece feeding.
• Working size 11.81"D x 59"L (300 x 1500mm)
• One blade head + one electronic spindle head combination
• AC servo 5.36HP (4.0KW) as head stock drive
• NEMA34 stepping motor + YAKO YAK2811MA combination as the X and Y drive
• RichAuto hand-held numerical controller special for auto wood lathe, which can read ***.dxf file and no need to make G-code toolpath for turning and broaching jobs. The communication interface is USB.
