- Type: Wallpapers
- Wallpapers Type: Other
- Place of Origin: Liaoning, China (Mainland)
- Brand Name: Youbang
- Model Number: YB-M6091-29
- Function: Fireproof, Heat Insulation, Mould-Proof, Soundproof
- Usage: Administration, Commerce, Entertainment, Household
- Style: Other
- Size Max Width: 1220mm, Max Length: 2800mm
- Thickness: 3-12mm
- Density: 0.95g/cm³
- bending: 19.5mpa
- PVC veneer thickness: 0.5-1mm
- typical moisture content: 6%
- drying shrinkage: 0.26%
- moisture movement: 0.50%
- ITEM: 96
Our panel wall decorative applies MgO board as the base material, and high press laminates & pvc as the skin.
Cold pressed working is used to produce the composite panel. Since the fire grade of MgO board and fiber
cement board is A1, and PVC is B2, so the finished product is still fireproofing.
Applicatio
Partition and ceiling in the room, office building, hotel, hospital, airport, subway, gymnasium, library, museum, theater, factory building, computer laboratory, indoor natatorium. It is also used as the backing-lining, fireproof door and other wallboard, outdoor bill-board;base plate of various kinds of plaques; outside board of the ventilation shaft and steel construction; roof boar ding; electric wire and cable wraps up and applies etc.
Product Details
|
Skin
|
PVC & hpl one side or two sides lamination
|
|
The Surface of PVC
|
Matt, Glossy, Relief, Grain, etc.
|
|
Base Material
|
Magnesium Oxide Board
|
|
Glue
|
E0
|
|
Size
|
Max Width: 1220mm, Max Length: 2800mm
|
|
Thickness
|
3-12mm
|
|
PVC veneer thickness
|
0.5-1mm
|
The standard size is 1220*2440mm with the thickness below 12mm.
|
Density
|
0.95g/cm³
|
|
Bending strength
|
19.5MPa
|
|
Typical moisture content
|
6%
|
|
Drying shrinkage
|
0.26%
|
|
Moisture movement
|
0.50%
|
|
Impact strength
|
6.2KJ/m²
|
|
Pull put force of Screw
|
37.1N/mm
|
|
Non combustible performance
|
According to GB8624-1997, Combustibility is A1 Class.
|
|
Fire rating limited
|
6mm:>2Hours; 12mm:>4Hours;
|
|
Thermal Coefficient
|
0.109W/(m.k)
|
Feature
1. Fireproof
It was tested by the National Center for Quality Supervision and Testing of Fire Building Materials (NFTC). Its fireproof level is rated level A (nonflammable level)
2. Dam proof
It is excellent in moisture-resistance. Dry bending strength is 15Mpa. Bending strength under absorbed moisture is 22Mpa.
3. Heat insulation
It has heat prevention material incorporated, it has great feature of heat prevention. Thermal resistance is 1.14m2k/w.
4. Soundproof
It is proved to have good noise insulation property after inspected by the National Center for Quality Supervision and Testing of Fire Building Materials (NFTC), The noise insulation factor of the wall can reach 44dB and 47dB. It has the best noise insulation constitution in China, especially the 95mm wall comprised by the 10mm board.It is light, it can save time, space, weight and expense. It is a new and high efficient wall.
5. Compact resistance
It is a light board. Its density is less than 1.0×1.03kg/m3. At the same time its bending strength and impact resistance is excellent. Also, it will maintain its' quality during construction. .
Tools & Accessories
We can also provide the accessories , such as:
1. Main channel, furring channel,wall ange, U track etc, sizes upon your detailed request
2. Joint compound: 5kg/bag
3. Drywall screws: 3.5mmx25mm,3.5mmx35mm,3.5mmx50mmm etc
4. Paper Joint Tape: 50mmx50m etc
5. Self adhesive fibre glass tape: 50mmx90m etc
