DYJ Series Portable Anti-Explosion Lubricating Oil Purifier

DYJ Series Portable Anti-Explosion Lubricating Oil Purifier
  • DYJ Series Portable Anti-Explosion Lubricating Oil Purifier
Share to:

1) Vacuum Oil Purifier 2) Latest vacuum dehyration principle 3) Flash Distillation technique 4) Purifying transformer oil

Product Details


Condition: : New
Flow: : 1000L/MIN
Working Pressure: : less than 0.5MPA
Place of Origin: : Chongqing
China : Brand Name:
WANMEI : Model Number:
DYJ-1000LB : Usage:
Insulation Oil : Voltage:
380V : Power(W):
496000 : Dimension(L*W*H):
280*200*250CM : Weight:
4600KGS : Certification:
ISO9001 : After-sales Service Provided:
Engineers available to service machinery overseas : Certificate:
TUV Rheinland : Brand:
OEM available : Warranty:
One year : Color:


DYJ Series Portable Anti-Explosion Lubricating Oil Purifier
DYJ Series portable anti-explosion Lubricating Oil Purifier

General Description:
DYJ series oil purifier is a kind of multi-function equipment for dehydration, degassing, and purification process of lubricating oil. It is developed and produced by Wanmei company to deal with different kinds of lubricating oils of various types of kinematical viscosity and flash point. It is ideal equipment for factories, mines, and other enterprises to purify different kinds of lubricating oils. The double-stage and multi-stage oil purifier are more efficient in their operation.
In view of customers’ special requirement, we have also developed DYJ-B series of semi-automatic lubricating oil purifier, DYJ-Q automatic multi-function lubricating oil purifier and DYJ-Ex anti-explosion multi-function lubricating oil purifier. It is suitable to work in different conditions.
Application scope: It is widely used in metallurgy, machinery, oil field, chemistry, mine, electric power generation plant, transportation and manufacturing enterprises for hydraulic oil, gear oil, engine oil, compression oil, freezer oil, heat treatment oil, refrigerator oil, etc. It can quickly break emulsion in oil, remove water, gas and mechanical impurities, light acid and light hydrocarbon from oil, and improve oil quality, resume its lubricating property and ensure normal operation of the equipment.
Typical Characteristics:
1. Super ability in breaking emulsion, dehydration and degassing process. Import and adopting advanced  technique in big-cubage, reinforced three-dimension flash distillation column,  coalescence and separation technique,  thin film evaporation technique and large area multi-level separation technique and  spraying technique, so as to remove water, gas and light hydrocarbon materials efficiently and quickly from oil.
2. Precise multi stage filtration system. Adopting high-quality filter element and sealing material with corrosion proof, high temperature resistance and excellent mechanical strength, it is suitable even for purification process of high-viscosity oil under rather high temperature conditions and thus expanding its application scope. It greatly helps remove metal and mechanical particulates thoroughly and effectively from oil.

3. Safe and reliable electrical heating system. The electrical heater is installed with vortex tube heating element to keep the temperature even and constant, with the merits of quick heating, inter cycling, auto overload protection, and free preset of temperature range.
4. Advanced auto control system. The equipment is installed with advanced high pressure protection device, float and infrared oil level controller and auto de-foaming system. It can work on line and on site without human supervision. If the fine filter is blocked by impurities and the working pressure increases, the whole machine will stop automatically.

5. Efficient air-cooling and condensation system, It is installed with air cooling radiator to cool down steam, gases and air from the vacuum distillation column. Steam is condensed into water and leads to the water drainage tank. Air and gases is let out to atmosphere.
6. Reliable quality for efficie

Company Profile

wanmei logo
Chongqing Wanmei Electric & Machinery Co., Ltd. and Chongqing Wanmei Oil Purifier Research Institute are high-tech enterprises for research, development and production of oil purification equipment, automatic water purifier, gasifier and other electrical maintenance equipment. The company has unique capability in scientific research and equipment production, with the help of professional scientific experts, specialists and other technicians. Over 70% of the company's staff members are graduates from various colleges.
The company lays much emphasis on high technology research and applications to practical production, gaining a lot of patented technique certificates, know-how certificates, and ISO9001 international certificate. It is granted with independent right for international trade. "Wanmei" trademark has been registered in the People's Republic of China, and "Wanmei" brand has been widely acknowledged in the world market.
Wanmei has assigned to itself the great task of "saving natural resources and protecting biological environment". It has developed 32 series and 280 different models of products, based on the latest scientific research and advanced technology both in China and abroad. All these products are working properly in different industries of electrical generation, petroleum, chemistry, metallurgy, machinery, mining, aviation, ship-building, railway transportation, and so forth. Wanmei oil purifier is characteristic for its fine filtration, steady operation, energy saving, auto control and easy maintenance, which has won high praises from our customers all over the world.
Wanmei gives its guarantee to all customers both at home and abroad of reliable quality products, reasonable price and good service. We will serve our new and old customers with "Wanmei technology, Wanmei products, Wanmei quality, Wanmei service and Wanmei credit", and open up a brilliant new prospect together with all our customers.
