Introduction of the basket strainer
The basket strainer is composed of filter body ,filter basket ,filter cover and inlet outlet . When the liquid come into the filter basket ,the particle stay at the inside of the basket ,the clean liquid come out from the outlet . Liquid flow through the filter, which filters out impurities to be, to protect pump, compressors, instrumentation and other equipment to work properly. When cleaning, as long as the removable cartridge removed, filtered to remove impurities, to re-load, the use of extremely easy to maintain.
Application of the basket strainer:
It is piped to remove solid impurities in the process of the equipment.
The chemical and petrochemical production and weak corrosive materials, such as: water, oil, ammonia, hydrocarbons, etc..
Corrosive materials, chemical production such as caustic soda, soda ash, sulfuric acid, carbonic acid, etc..
Low temperature refrigeration materials, such as: liquid methane, ammonia, oxygen and refrigerant.
|
Item
|
Parameters
|
|
Material
|
SS304 ,SS316L ,Carbon steel ,PTFE lining
|
|
Operate pressure
|
0-25.0 bar
|
|
Flange pressure code
|
JIS 5K,10K,16K,ANSI CLASS 150
|
|
Operate temperature
|
0-300 DegC
|
