O Series HD Small Pixel LED Video Wall,High definition,High definition LED Display
Item: 16*9 HD Small Pixel LED Video Wall.
Applications: TV Stations, Conferences, Home Theaters
Certificates: FCC, CE, EMC, LVD.
Services: 5 Years Warranty
|
Small Pixel 16:9 LED Screen Specification
|
|
Item
|
O Series
|
O Series
|
O Series
|
O Series
|
|
Pixe Pictch
|
1.25mm
|
1.56mm
|
1.875mm
|
2.5mm
|
|
Scan Mode
|
1/30 Scan
|
1/24 Scan
|
1/30 Scan
|
1/30 Scan
|
|
Pixe Per Sq.m
|
640,000 Pixel
|
409,600 Pixel
|
284,444Pixel
|
160,000 Pixel
|
|
Led encapsulation
|
SMD1010
|
|
Maintenance methods
|
Front/Rear Service Both
|
|
Cabinet Material
|
Die Casting Aluminum
|
|
Module Size(W*H)
|
160*180mm
|
|
Cabinet Size(W*H*D)
|
640*360*58mm
|
|
Refresh Rate
|
3840hz
|
|
Color temperature
|
10000K ±500（Adjustable）
|
|
Grey Scale
|
16bits
|
|
Cabinet Weight
|
7.4KG/Pieces
|
|
Brightness(Nits/㎡)
|
1000nits
|
|
Average Power Consumption
|
100Watt/Pieces
|
|
Max Power Consumption
|
200Watt/Pieces
|
|
IP Protection
|
IP43
|
|
Operating Temperature
|
-10°C to 40°C
|
|
Working Voltage
|
110-240Volt(50-60hz)
|
Hot Sale LED Video Wall, which include Outdoor Advertising Screens, Indoor Rental LED Screen, Floor Standing LED Display, See-Through LED Display, HD LED Vedio Panel. Low price, high quality. All LED Video Display provides 5 years warranty service.
If you want to know more product information, please click here
