Optical bi-convex lens,bk7 glass,AR Coated,2mm,5mm,8mm,18mm,20mm

Optical bi-convex lens,bk7 glass,AR Coated,2mm,5mm,8mm,18mm,20mm
  • Optical bi-convex lens,bk7 glass,AR Coated,2mm,5mm,8mm,18mm,20mm
  • Optical bi-convex lens,bk7 glass,AR Coated,2mm,5mm,8mm,18mm,20mm
Share to:

Min.Order Quantity: 1 Piece/Pieces Supply Ability: 50000 Piece/Pieces per Month Port: Changchun Payment Terms: L/C,T/T,Western Union,paypal

Product Details

Parameter

Shape : Plano
Structure : Double Convex
Usage : Optical
Material : bk7
Model Number : SPL
Brand Name : SUNDAY
Place of Origin : Jilin, China (Mainland)
surface quality : 40/20 or better

Description

Packaging & Delivery

Packaging Details: carton case,firm and safe package for air transmission
Delivery Detail: 7-30days

Specifications

Double Convex lens
1.Material:BK7
2.Dia.:,2mm,5mm,8mm,18mm,20mm
3.S/D:40/20
4.flatness:1/4lambda

 Optical Glass Bi convex lens

Bi-convex lens is manufactured with an identical convex surface on both sides of the lens

Bi-convex lenses have positive focal lengths and form both real and virtual images.





Structure

                          Bi convex lens

Substrate Material

BK7/K9

Diameters Available

                     2mm,5mm,8mm,18mm,20mm

Diameter Tolerance

+0.00/-0.10 mm

Surface Quality

40-20 Scratch-Dig(general) 10-5 to 80-50 is availble

Surface Flatness

1/20 lambda to 3lambda

Surface Irregularity
(Peak to Valley)

λ/4

Thickness tolerance

+0/-0.1mm

Focal length tolerance

+/-1%

Clear Aperture

>90% of Diameter

Chamfer

0.05-0.5mmx45degree,according to customer’s needs.

Centeration

3 arcmin

Coating

AR,Mgf2 is on request,R<0.25%

Visible wavelength,laser wavelength
