Auto-reset or power-off reset optional for 4 wire connection
Features
Smoke alarm Designed to comply with EN-54 standard
Two or four wire models optional
Low power consumption, high precision and stability
Durable Sensor Head; Excellent smoke access
Power-off reset for 2 wire connection
Easy Installation and maintenance
Extended Warranty
Characteristic
Dual LEDs for 360-degree visibility
Twist-off mounting for fast installation
Technical Data:
Model
S21P-2
S21P-4
Operating Voltage
DC 9~35V
Standby Current
55uA
12mA(NC);2mA(NO)
Alarm Current
22mA@DC12V;40mA@DC24V
3mA(NC);15mA(NO)
Detecting Area
80 square meter(with the installation height of 6m-12m), and 60 square meter(with the installation height less than 6m)
Alarm Output
Conventional Output and LED flash
Relay output (N.O/N.C) and LED flash
Installation Method
Ceiling Mounted
Operating Temperature
-10°C ~ +55°C
Operating Humidity
less than or equal to 95%RH(max)
Dimensions
100mm(Dia)x46mm(H)
