Miaxis Model SM-621B V10

USD 0.00-1.00 / Unit/Units | 100.00 Unit/Units (Min. Order)

Processing Time: 4-5 weeks

Packaging Details: outside box

Port: Hangzhou

Payment Terms: L/C , T/T , other

Send Inquiry Add to My Favorites

Share to:

Basic Information

Brand Name

miaxis
Place of Origin

china

Brief description

Biometric Hardwares

Detailed description

Miaxis Model SM-621B V10 Fingerprint Authentication Modules

Biometric OEM Module

OVERVIEW:

Miaxis Model SM-621B V10 is a highly cost-effective integrated optical fingerprint module equipped with powerful CPU and high quality optical sensor with advanced CMOS technology.

The module allows standalone operation with on-board fingerprint image processing, template extraction, fingerprint matching (including 1: 1 and 1: N), template storage and other functions.

Optical Fingerprint Sensor FEATURES:

• 500 dpi resolution

• Large image capture area

• Durable optical sensor surface

• Miaxis proprietary fingerprint algorithm

• Flexible security setting

fingerprint authentication modules SPECIFICATION:

Specification	SM-621B V10
CPU	200MHz, Cortex-M4F
Flash memory	256KB (Expandable up to 1MB)
Product size(L x W x H)	55.0×22.0×24.5mm
Sensor type	Optical
Active platen area	12.8*15.2mm
Image Size	256*304 pixel
Image resolution	500 dpi
Grey scale	4 bit
Power-on time	≤200ms
Enrollment time (Finger touch to template)	≤350ms
1:1 Verification time*	≤150ms
1:N Matching time	≤1s,N=128
FAR	≤0. 001 %
FRR	≤1 %
Template size	256 bytes default
Fingerprint capacity	256 templates (Expandable)
ESD immunity	±8kV contact discharge ±15kV air discharge
Supply voltage	DC 3.8V-7.0V
Supply current	≤80mA
Supply current Sleep mode	≤10uA
Communication interface	UART
Baud rate	57600(default), 5 options
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +60°C
Operating humidity	20%RH～90%RH

Note: the 1:1 verification time* is calculated based the time of input template matched to the stored template.

The company is Chinese's industry-leading developer and manufacturer of biometric system and fingerprint recognition algorithm. Based on over 18 years of industry experience and we are the key vendor of fingerprint scanner for Chinese resident ID card program approved by the ministry of Public Security.

If you are interested in our products, please click here!

Company Profile

Founded in 2000 and headquartered in Hangzhou, Miaxis Biometrics Co., Ltd, a subsidiary of XGD******, is Chinese’s industry-leading developer and manufacturer of biometric fingerprint devices and multi-biometrics systems (facial,fingerprint,finger vein etc) for identity management with core technologies of image processing and world renowned biometric recognition algorithms.

We provide both advanced capacitive & optical fingerprint scanner and verification terminal series and turnkey biometric solution including smart E-door lock system solution, visiting access control management soluiton, bank teller fingerprint management solution and so on, widely applied to finance, security, government affairs, police, home automation industries.

Based on over 18 years of industry experience, Miaxis is the pioneer of fingerprint recognition technology in domestic financial industry with more than 50% market share and key vendor of fingerprint scanner for Chinese resident ID card program approved by the ministry of Public Security.
